Electric PPR butterfly valve

  • [Valve model]: D971S,D971X
  • [Diameter specification]: DN40～DN300mm
  • [Structure]: Midline
  • [Valve body material]: UPVC、CPVC、PP、PVDF
  • [Nominal pressure]: PN10
  • [Applicable temperature]: -40℃ - 180℃
  • [Application Scope]: Ordinary pure water and raw drinking water, acid and alkali, corrosive liquid
Consult the manufacturer Online Message
  • Electric PPR butterfly valve

Product features

The electric PP plastic butterfly valve has excellent corrosion resistance, and the valve body is light in weight, sanitary and non-toxic in material, wear-resistant, non-toxic, odorless, tasteless, milky white high crystalline polymer, which can resist corrosion of ordinary inorganic acids, alkalis, salts, gases, water, etc. except for oxidation at 80 ℃, and has greater resistance to polar organic solvents, strong polar carboxylic acids, alcohols, etc. The electric PP butterfly valve is corrosive to a small number of oxidizing acids at high concentrations, and has certain rigidity and strength. The applicable temperature is - 0~120 ℃.
Features of electric PP butterfly valve:

The electric PP plastic butterfly valve has compact and beautiful appearance, light weight, easy installation, strong corrosion resistance, wide application range, wear resistance, easy disassembly, and simple maintenance. It has been applied in many fields, such as the pipeline system of general pure water and raw drinking water, drainage and sewage pipeline system, brine and seawater pipeline system, acid and alkali and chemical solution system, etc.

technical parameter

Nominal diameter DN40～DN300(MM)
Nominal pressure PN0.6、1.0MPa
Connection mode Wafer type
Drive type Power drive AC220V, AC380V, DC24V (other special)
Applicable temperature -40℃～180℃
body material UPVC、RPP、CRVC、PVDF
Sealing material
NBR (X), FKM, EPDM (E)
Control form Switch type (switch two position control), regulating type (4-20mA analog quantity control)

Optional functions of electric PP butterfly valve:
  Optional Features
Explosion proof function Protection grade: equivalent to IP65 (or IP67), explosion-proof sign: Exd Ⅱ BT4
Adjustment function Input and output 4-20mA, O - 5V DC、0- 10V. DC
Manual function It can be equipped with manual device, which can open and close the valve
Relevant temperature Ambient temperature: - 25~+70 ℃, ambient humidity: ≤ 95%

Quotation process

Valve price:

Due to the different requirements of order quantity, packaging and delivery method, and the fluctuation of the price of valve raw materials, the price of valves will have a big difference immediately, so our products have not been marked with prices on the website, please understand.

If you select a valve product on this website and need to know the price or obtain relevant technical information, please contact us. We will reply immediately, and can select appropriate valve products for you according to your requirements, so that your procurement process is easy and pleasant.

Quotation process:

1. Please fax the name (or product model) of the valve you selected, the required order quantity, packaging requirements, delivery time, your company name, your company location and contact information to 021-36311208 Or telephone: 021-60547555。

2. After receiving the customer's purchase list, our company will provide the customer with various services such as valve quotation "price list", model selection "valve model" and technical guidance as soon as possible.

3. Specific matters: delivery date, special requirements, etc.

Ordering Instructions

1、 If the customer has special requirements for the product, the following instructions must be provided in the order contract:
(1) Valve body material (such as plastic, cast steel, stainless steel...)
(2) Connection type (such as flange, thread, clamp, etc.)
(3) Nominal diameter, pipe size
(4) Ambient temperature and pressure range
(5) Power supply voltage, air supply pressure
(6) Fluid properties (including nominal pressure, temperature, viscosity or acid-base)
2、 The company configures various driving devices according to the special requirements of customers. (electric control, pneumatic control)
3、 If the customer provides the determined valve type and model, the customer should correctly explain the meaning and requirements of the model (see the description of valve model preparation for details), and sign the contract on the condition that both the supplier and the buyer have the same understanding.
4、 After the customer tells the required valve model, specification, quantity, delivery time and place, the deposit of 20% of the total amount or the full payment for goods shall be remitted to our company's account in time, and the rest of the payment for goods shall be remitted before shipment, so as to arrange shipment in time.
5、 After the purchase is confirmed, our company will produce in strict accordance with the delivery date. The product processing cycle is generally 3 to 30 days, depending on the type and quantity of the order, and the specific delivery time is subject to the contract. In order to ensure that the goods you ordered are in place in time, please try your best to order earlier.
6、 Our company provides network distribution services according to the needs of customers, delivering goods to the branches (offices) of customers in major cities, and implementing door-to-door delivery services. After the products are accepted, our company will provide after-sales service.
